| RC-80 | RC-100 | RC-120 | |
| Rated power (8Ω): | 120W | 200W | 300W |
| Max power: | 250W | 400W | 600W |
| Input： | 8Ω | 8Ω | 8Ω |
| (level of) sensitivity（1W/1M)： | 101dB±3dB | 103dB±3dB | 105dB±3dB |
| Frequency Response: | 80Hz -18KHz | 75Hz -18KHz | 60Hz -20KHz |
| Radiation angle: | ∠110° | ∠100° | ∠120° |
| Speaker unit: | 8''x1 1.75''x1 | 10''x1 1.75''x1 | 12''x1 1.75''x1 |
| Product Size (HxWxD)： | 302x312x260mm | 345x355x297mm | 375x435x395mm |
| Colour： | Black/White | Black/White | Black/White |
| Product weight： | 7.8 KG | 13KG | 18.6KG |
| Protection level： | IP65 | IP65 | IP65 |
| Packaging specification: | 1pc/ctn | 1pc/ctn | 1pc/ctn |
| Package sizemm | 385X370X330 | 450x440x385 | 535X500X495 |
| Housing Material: | Plastic housing + aluminium grille + stainless steel bracket | Plastic housing + aluminium grille + stainless steel bracket | Plastic housing + aluminium grille + stainless steel bracket |
| RC-80F | RC-100F | RC-120F | |
| Rated power (100V): | 18W/37.5W/75W/150W | 25W/50W/100W/200W | 25W/50W/100W/200W |
| Rated power (70V): | 9W/18W/37.5W/75W/150W | 12.5W/25W/50W/100W/200W | 18.5W/37.5W/75W/150W/300W |
| Rated power (8Ω): | 150W | 200W | 300W |
| Max power: | 250W | 400W | 600W |
| Input： | 70V/100V/8Ω | 70V/100V/8Ω | 70V/100V/8Ω |
| (level of) sensitivity（1W/1M)： | 101dB±3dB | 103dB±3dB | 103dB±3dB |
| Frequency Response: | 80Hz -18KHz | 70Hz-18KHz | 70Hz-20KHz |
| Radiation angle: | ∠110° | ∠100° | ∠120° |
| Speaker unit: | 8''x1 1.75''x1 | 10''x1 1.75''x1 | 12''x1 1.75''x1 |
| Product Size (HxWxD)： | 302x312x260mm | 345x355x297mm | 375x435x395mm |
| Colour： | Black/White | Black/White | Black/White |
| Product weight： | 9.1 KG | 13.5KG | 20.3KG |
| Protection level： | IP65 | IP65 | IP65 |
| Packaging specification: | 1pc/ctn | 1pc/ctn | 1pc/ctn |
| Package sizemm | 385X370X330 | 450x440x385 | 535X500X495 |
| Housing Material: | Plastic housing + aluminium grille + stainless steel bracket | Plastic housing + aluminium grille + stainless steel bracket | Plastic housing + aluminium grille + stainless steel bracket |
